AIR-M200-20 blowing nozzle, blowing force regulation at 5 bar: 9.1 N, air consumption at 5 bar: 56 Nm³/h, aluminum

Name: AIR-M200-20 blowing nozzle, blowing force regulation at 5 bar: 9.1 N, air consumption at 5 bar: 56 Nm³/h, aluminum - Walter Krupp
SKU: IJTI0TEI
Price: 64.05 EUR
Availability: InStock

Add to wishlist

Read product description

Für individuelle Preisanzeige bitte anmelden.

Add to wishlist

For individual price display please Login

Or register quickly and easily:

Immediate activation
Purchase on account (from 2nd order), Paypal, credit card, bank transfer
Our specialist consultants and engineers will take care of your machining task or technical question
Same-day dispatch of tools and machines in stock

Description
Technische Informationen

The Airmasters range of compressed air blowing nozzles is the largest selection in the world! Ideal where blow-off requires a high technical standard and where high noise levels and consumption cause serious problems. Blowing off, cooling and drying are just a few examples of applications where our air blast nozzles are used.
The blow nozzles are designed to deliver a powerful jet of air while minimizing compressed air consumption and noise levels. Savings: Our blow nozzles replace pipes with a diameter of 2 mm to 25 mm, enabling energy savings and a return on investment within a few weeks! Our tuyeres are available in 316L stainless steel, 304 stainless steel, aluminum and zinc.
Safety: All our nozzles comply with OSHA and SUVA standards, which means that the air blown out of the nozzle must not exceed a pressure of 2.1 bar when in contact with the operator’s skin. This eliminates the risk of embolism if air is blown under the skin through an open wound. Noise: Airmasters’ blowing nozzles guarantee a reduction in noise levels of more than 50% compared to an open tube or homemade device.

SKU: IJTI0TEI Kategorie: Blowing nozzles

Description
Technische Informationen

Luftstromverstärkung	50:1
Abstandsfolien	Stainless steel, Stainless steel
Form Luftstrom	Even, Even
Maximaler Verbrauchsdruck	10 bar, 10 bar
Geräuschpegel bei 5 bar	82 dB(A)
Entspricht den OSHA-Richtlinien	Yes, Yes
Anschluss	Female 1/4" BSP, Female 1/4" BSP
Material	Harteloxiertes Aluminium
Abmessungen	51x20x52,5 mm
Blaskraftregulierung bei 5 bar	9.1N
Luftverbrauch bei 5 bar	56Nm³/h
Niedriger Geräuschpegel	26 dB(A)
Ersetzt offenes Rohr	8 mm
Lufteinsparung Nm³ / h	62Nm³/h

AIR-M200-20 blowing nozzle, blowing force regulation at 5 bar: 9.1 N, air consumption at 5 bar: 56 Nm³/h, aluminum
